PPM-C400GS Specs

Model:

PPM-C400GS

X/Y Axis Moving Range:

639×656mm

Mounting Numbers:

6PCS

X/Y Axis drive type:

Lead Screw + Guide Rail

Mounting Precision:

0.025mm

X/Y Axis drive motor:

Panasonic Servo Motor

Mounting Angle:

0~360°

Z Axis Moving Range:

10mm

Mounting Speed:

11000pcs/hour

Z Axis Rotation Angle:

0~360°

Suction Nozzle Type:

Juki Series Nozzle

Visual Camera

CCD High-definition Camera

Applicable Element:

RC (0402, 0603, 0805, 1206 etc)

LED Lamp Beads (0603, 0805, 3014, 5050 etc)

Chip (SOT, SOP, QFN, BGA etc)

SMD Height:

≤6mm (Customize ≤11mm)

Numbers of Visual:

Parts Camera×7, PCB Camera×1

PCB Minimal Size:

45×45mm

Recognition Capability:

MAX. 45×45mm

PCB Maximum Size:

500×400mm

PC System:

Microsoft WIN7

PCB Thickness:

≤2mm

Operational Software:

FlyerSMTli

Components Reel Type:

8mm, 12mm, 16mm, 24mm, 32mm

Compatible File Format:

CSV. TXT. Format

 Feed type:

YAMAHA CL Feeder

Program Method:

Support Online and Offline Ways

Electric feeder:

3pcs

Vacuum Mode:

Vacuum Generator

Vibration Stick Feeder:

5 Channels

Vacuum Value:

-80kpa

IC Tray:

2pcs

Power:

350W

Voltage:

AC220V±10% 50Hz

Net Weight:

350kgs

Gross Weight:

396kgs

Machine Size:

L1335×W1200×H1390mm

Package Dimension:

1416*1460*1485mm
